Corbin Russwin Exit Devices

Barzel Lock Stocks All Corbin Russwin Exit/Panic Devices
Corbin Russwin ED 8200 Rim Exit Device

Corbin Russwin ED 8200 Rim Exit Device

by Corbin Russwin
$ 255.00

Corbin Russwin ED 8200 Rim Exit Device

Handing- Non-handed.

Finishes:

689-Aluminum Painted

691-Light Bronze Painted

Bar Length: Easily field cut to size.

Standard: 36" bar fits 31" - 36" (787mm-914mm) door.

Optional: 30" bar fits 28" - 30" (711mm-762mm) door; .

Optional: 42" bar fits 37" - 42" (940mm-1067mm) door; .

Optional: 48" bar fits 43" - 48" (1092mm-1219mm) door; .

Door Thickness: 1-3/4" (44mm) standard.

Backset: 2-3/4" (70mm). Device and trim cover standard

Latchbolt: 3/4" (19mm) stainless steel pullman-type with stainless steel deadlocking latch

Materials: Heavy-duty wrought steel chassis and pushpad; aluminum front and rear bar covers; stainless steel springs; nylon bearings.

Dogging: Standard on ED8200 devices: single point 1/4 turn dogging.

Optional: less dogging; specify M51(Call To See If Its Avail.).

Fasteners: Standard on ED8200 devices: machine screws and wood door fasteners.

Certification/Compliance ANSI Meets A156.3, Type 1, Grade 1. Meets A117.1 Accessibility Code. C-UL US All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. UL symbol on rear cover label indicates listing. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 4' x 8' single or 8' x 8' double doors; UL symbol on rear cover label indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. Warnock Hersey International Inc. ED8200B listed as fire exit hardware for installation on up to 1-1/2 hour fire doors, up to 8' x 8'. California State Reference Code This product has been approved by the California State Fire Marshal (CSFM) pursuant to Section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Exit devices, lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED 8200A Fire Rated Rim Exit Device

Handing- Non-handed.

Finishes:

689-Aluminum Painted

Bar Length: Easily field cut to size.

Standard: 36" bar fits 31" - 36" (787mm-914mm) door..

Door Thickness: 1-3/4" (44mm) standard.

Backset: 2-3/4" (70mm). Device and trim cover standard

Latchbolt: 3/4" (19mm) stainless steel pullman-type with stainless steel deadlocking latch

Materials: Heavy-duty wrought steel chassis and pushpad; aluminum front and rear bar covers; stainless steel springs; nylon bearings.

Dogging: Standard on ED8200 devices: single point 1/4 turn dogging.

Optional: less dogging; specify M51(Call To See If Its Avail.).

Fasteners: Standard on ED8200 devices: machine screws and wood door fasteners.

Certification/Compliance ANSI Meets A156.3, Type 1, Grade 1. Meets A117.1 Accessibility Code. C-UL US All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. UL symbol on rear cover label indicates listing. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 4' x 8' single or 8' x 8' double doors; UL symbol on rear cover label indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. Warnock Hersey International Inc. ED8200B listed as fire exit hardware for installation on up to 1-1/2 hour fire doors, up to 8' x 8'. California State Reference Code This product has been approved by the California State Fire Marshal (CSFM) pursuant to Section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Exit devices, lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED4200 Narrow Stile Rim Exit Device

Corbin Russwin ED4200 Narrow Stile Rim Exit Device

Handing: Device non-handed.

Instructions

Bar Length: Easily field cut to size.

Standard: 36" (914mm) bar fits 30"- 36"

Optional: 48" (1219mm) bar fits 36"- 48" (914mm-1219mm) door; specify W048.

Finishes:

630-Satin Stainless Steel

613-Oil Rubbed Bronze

606-Satin Brass

Door Thickness: 1-3/4" (44mm) standard

Latchbolt: 3/4" (19mm) throw, pullman type with stainless steel deadlocking latch.

Dogging Standard: single point 1/4 turn hex key dogging.

Contact Us To See If We Have These Options In Stock

Optional: less dogging; specify M51.

Optional: cylinder dogging; specify M52.

Optional: electric dogging; specify M97.

Strike: Surface mounted 3/8" (10mm) diameter roller strike, complete with positive locking plate and shims.

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 4, Grade 1. Meets A117.1 Accessibility Code. UL/cUL All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. UL symbol on active case cover indicates listing. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. ADA Exit devices, lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED4400 Narrow Stile Surface Vertical Rod Exit Device

Handing: Device is handed but easily field reversible.

Finish:

630-Satin Stainless Steel

613-Oil Rubbed Bronze

Bar Length: Easily field cut to size. Standard: 36" (914mm) bar fits 30"- 36" (762mm-914mm) door

Door Thickness: 1-3/4" (44mm) standard.

Stile: Minimum width 2" (51mm).

Door Height: Standard: Top rod for 7' door. All top rods easily field cut to size.

Latchbolt: Top: 3/4" (19mm) throw, pullman type with automatic deadlatching. Bottom: 5/8" (16mm) throw deadbolt, held retracted during door swing

Vertical Rods: 1/2" O.D. tubular brass, bronze or stainless steel with rod guides

Materials: Heavy-duty cold-forged steel chassis; heavy-gauge steel mechanisms, electroplated for corrosion resistance; finished parts are brass, bronze or stainless steel; stainless steel springs; nylon bearings.

Projection: 3-1/4" (83mm) active, 2-3/4" (70mm) dogged.

Dogging: Standard: single point 1/4 turn hex key dogging.

Fasteners: Standard: machine screws.

Strike: Top: Adjustable roller strike with positive locking plate and shims. Bottom: flush mounted.

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 5, Grade 1. UL/cUL All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. UL symbol on active case cover indicates listing. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. ADA Lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED5200 Rim Exit Device

Corbin Russwin ED5200 Rim Exit Device

by Corbin Russwin
$ 720.00

Corbin Russwin ED5200  Rim Exit Device

Handing: Standard Device is non-handed.

ED5200 Installation Instructions

ED5200 Product Templates

Bar Length: Easily field cut to size.

Standard: 36" (914mm) bar fits 30"- 36"

Optional: 48" (1219mm) bar fits 36"- 48" (914mm-1219mm) door; specify.

Finishes:

630-Satin Stainless Steel

613-Oil Rubbed Bronze

606-Satin Brass

Door Thickness: 1-3/4" (44mm) standard

Latchbolt: 3/4" (19mm) throw,Stainless Steel pullman type with stainless steel deadlocking latch.

Dogging Standard: single point 1/4 turn hex key dogging.

Contact Us To See If We Have These Options In Stock

Optional: less dogging; specify M51.

Optional: cylinder dogging; specify M52.

Optional: electric dogging; specify M97.

Strike: Surface mounted 3/8" (10mm) diameter roller strike, complete with positive locking plate and shims, assuring low friction relocking for a long, trouble-free life.

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 1, Grade 1. Meets A117.1 Accessibility Code. UL /cUL All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 4' x 8' single or 8' x 8' double doors; UL symbol on active case cover indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Exit devices, lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED5200A Fire Rated Rim Exit Device

Corbin Russwin ED5200A Fire Rated Rim Exit Device

Handing: Standard Device is non-handed.

Instructions

Bar Length: Easily field cut to size.

Standard: 36" (914mm) bar fits 30"- 36"

Optional: 48" (1219mm) bar fits 36"- 48" (914mm-1219mm) door; specify.

Finishes:

630-Satin Stainless Steel



Door Thickness: 1-3/4" (44mm) standard

Latchbolt: 3/4" (19mm) throw,Stainless Steel pullman type with stainless steel deadlocking latch.

Dogging Standard: single point 1/4 turn hex key dogging.

Contact Us To See If We Have These Options In Stock

Optional: less dogging; specify M51.

Optional: cylinder dogging; specify M52.

Optional: electric dogging; specify M97.

Strike: Surface mounted 3/8" (10mm) diameter roller strike, complete with positive locking plate and shims, assuring low friction relocking for a long, trouble-free life.

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 1, Grade 1. Meets A117.1 Accessibility Code. UL /cUL All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 4' x 8' single or 8' x 8' double doors; UL symbol on active case cover indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Exit devices, lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED5400 Surface Vertical Rod Exit Device

Corbin Russwin ED5400 Surface Vertical Rod Exit Device

Handing: Device is handed but easily field reversible. Lever trim is handed.

ED5000 Catalog

Finish:

630-Satin Stainless Steel

626-Satin Chrome

613-Oil Rubbed Bronze

612-Satin Bronze

Bar Length: Easily field cut to size. Standard: 36" (914mm) bar fits 30"- 36" (762mm-914mm) door Optional: 48" (1219mm) bar fits 36"-48" (914mm-1219mm) door; specify W048.

Door Thickness: 1-3/4" (44mm) standard.

Stile: Minimum width 4-1/2" (114mm).

Door Height: Standard top rod for 7' door. All rods easily field cut to size.

Latchbolt: Top: 3/4" (19mm) throw, stainless steel pullman-type with automatic deadlatching. Bottom: 5/8" (16mm) throw deadbolt, held retracted during door swing.

Vertical Rods: 1/2" O.D. tubular brass, bronze or stainless steel with rod guides.

Materials: Heavy-duty cold-forged steel chassis; heavygauge steel mechanisms, electroplated for corrosion resistance; finished parts are brass, bronze or stainless steel; stainless steel springs; nylon bearings.

Projection: 3-1/4" (83mm) active, 2-3/4" (70mm) dogged

Dogging: Standard on panic devices; single-point 1/4 turn hex key dogging.

Optional: Cylinder dogging less Cylinder,

Fasteners: Standard on panic devices: machine screws and wood door fasteners. Standard on fire-rated devices: sex nuts and bolts

Strike Top: adjustable roller strike with positive locking plate and shims. Bottom: flush mounted.

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 2, Grade 1. UL /cUL All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 8’ x 8’ double doors; ­UL symbol on active case cover indicates listing. Any retrofit or other field modification to a fire- rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED5400A Fire Rated Surface Vertical Rod Exit Device

Handing: Device is handed but easily field reversible. Lever trim is handed.

ED5000 Catalog

Finish:

630-Satin Stainless Steel

626-Satin Chrome

613-Oil Rubbed Bronze

612-Satin Bronze

Bar Length: Easily field cut to size. Standard: 36" (914mm) bar fits 30"- 36" (762mm-914mm) door Optional: 48" (1219mm) bar fits 36"-48" (914mm-1219mm) door; specify W048.

Door Thickness: 1-3/4" (44mm) standard.

Stile: Minimum width 4-1/2" (114mm).

Door Height: Standard top rod for 7' door. All rods easily field cut to size.

Latchbolt: Top: 3/4" (19mm) throw, stainless steel pullman-type with automatic deadlatching. Bottom: 5/8" (16mm) throw deadbolt, held retracted during door swing.

Vertical Rods: 1/2" O.D. tubular brass, bronze or stainless steel with rod guides.

Materials: Heavy-duty cold-forged steel chassis; heavygauge steel mechanisms, electroplated for corrosion resistance; finished parts are brass, bronze or stainless steel; stainless steel springs; nylon bearings.

Projection: 3-1/4" (83mm) active, 2-3/4" (70mm) dogged

Dogging: Standard on panic devices; single-point 1/4 turn hex key dogging.

Optional: Cylinder dogging less Cylinder,

Fasteners: Standard on panic devices: machine screws and wood door fasteners. Standard on fire-rated devices: sex nuts and bolts

Strike Top: adjustable roller strike with positive locking plate and shims. Bottom: flush mounted.

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 2, Grade 1. UL /cUL All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 8’ x 8’ double doors; ­UL symbol on active case cover indicates listing. Any retrofit or other field modification to a fire- rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED5800 & ED5800A Fire Concealed Vertical Rod Exit Device 630 finish

Handing: Device is handed but easily field reversible. Lever trim is handed.

Bar length: Easily field cut to size. Standard: 36" (914mm) bar fits 30"- 36" (762mm-914mm) door.

Finish: 630-Satin Stainless Steel

ED5800 & ED5800A Catalog

Door Thickness: 1-3/4" (44mm) standard

Stile: Minimum width 4-1/2" (114mm).

Door Height: Standard: top rod for 8' door.

Latchbolt: Top: 3/4" (19mm) throw, stainless steel pullman-type with automatic deadlatching. Bottom: 5/8" (16mm) throw deadbolt, held retracted during door swing.

Vertical Rods: 1/2" O.D. tubing, electroplated for corrosion resistance.

Materials: Heavy-duty cold-forged steel chassis; heavygauge steel mechanisms, electroplated for corrosion resistance; finished parts are brass, bronze or stainless steel; stainless steel springs; nylon bearings.

Projection: 3-1/4" (83mm) active

Dogging: Standard on panic devices; single-point 1/4 turn hex key dogging.

Fasteners: Standard on panic devices: machine screws. Standard on fire-rated devices: sex nuts and bolts.

Strike: Top: roller type. Bottom: flush mounted.

Applications and Listings: For use on metal doors only

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 8, Grade 1. Meets A117.1 Accessibility Code. UL/cUL All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 8' x 8' double doors; UL symbol on active case cover indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Exit devices, lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED8400 Surface Verticle Rod Exit Device

Corbin Russwin ED8400 Surface Verticle Rod Exit Device

Handing: Handed; specify hand.

Finish:

689-Aluminum Painted

691-Light Bronze Painted

Instructions

ED 8400 Catalog

Bar Length: Easily field cut to size.

Standard: 36" bar fits 31"- 36" (787mm-914mm) door.

Optional: 30" bar fits 28" - 30" (711mm-762mm) door; .

Optional: 42" bar fits 37" - 42" (940mm-1067mm) door; .

Optional: 48" bar fits 43" - 48" (1092mm-1219mm) door;

Door Thickness: 1-3/4" (44mm) standard.

Backset: 2-3/4" (70mm). Device and trim cover standard

Door Height: All top rods easily field cut to size. Standard on ED8400 devices: top rod for 7'6" door.

Latchbolts ED8400 devices: Top: 1/2" interlocking drop latch. Bottom: 5/8" pivoted.

Materials: Heavy-duty wrought steel chassis and pushpad; steel vertical rods; aluminum bar and latch covers; stainless steel springs; nylon bearings.

Dogging: Standard on ED8400 devices: single point 1/4 turn dogging.

Fasteners: Standard on ED8400 devices: machine screws and wood door fasteners.

Warranty: One-year limited.

Certification/Compliance ANSI Meets A156.3, Type 2, Grade 1. C-UL US All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. UL symbol on rear cover label indicates listing. Threehour fire-rated devices listed as fire exit hardware for A label and lesser class 8' x 8' double doors; UL symbol on rear cover label indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. California State Reference Code This product has been approved by the California State Fire Marshal (CSFM) pursuant to Section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED8400A Fire Rated Surface Verticle Rod Exit Device

Handing: Handed; specify hand.

Finish:

689-Aluminum Painted

691-Light Bronze Painted

Instructions

ED 8400 Catalog

Bar Length: Easily field cut to size.

Standard: 36" bar fits 31"- 36" (787mm-914mm) door.

Door Thickness: 1-3/4" (44mm) standard.

Backset: 2-3/4" (70mm). Device and trim cover standard

Door Height: All top rods easily field cut to size. Standard on ED8400 devices: top rod for 7'6" door.

Latchbolts ED8400 devices: Top: 1/2" interlocking drop latch. Bottom: 5/8" pivoted.

Materials: Heavy-duty wrought steel chassis and pushpad; steel vertical rods; aluminum bar and latch covers; stainless steel springs; nylon bearings.

Dogging: Standard on ED8400 devices: single point 1/4 turn dogging.

Fasteners: Standard on ED8400 devices: machine screws and wood door fasteners.

Warranty: One-year limited.

Certification/Compliance ANSI Meets A156.3, Type 2, Grade 1. C-UL US All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. UL symbol on rear cover label indicates listing. Threehour fire-rated devices listed as fire exit hardware for A label and lesser class 8' x 8' double doors; UL symbol on rear cover label indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. California State Reference Code This product has been approved by the California State Fire Marshal (CSFM) pursuant to Section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED4800 Narrow Stile Concealed Vertical Rod Exit Device.

Handing: Device is handed but easily field reversible.

ED4800 Catalog

Finish:

630-Satin Stainless Steel

613-Oil Rubbed Bronze

Bar Length: Easily field cut to size. Standard: 36" (914mm) bar fits 30"- 36" (762mm-914mm) door

Door Thickness: 1-3/4" (44mm) standard.

Stile: Minimum width 2" (51mm).

Door Height: Standard: Top rod for 8' door. Telescoping rod assembly to accommodate various door heights..

Latchbolt: Top: 3/4" (19mm) throw, pullman type with automatic deadlatching. Bottom: 5/8" (16mm) throw deadbolt, held retracted during door swing

Vertical Rods: 1/2" O.D. tubular brass, bronze or stainless steel with rod guides

Materials: Heavy-duty cold-forged steel chassis; heavy-gauge steel mechanisms, electroplated for corrosion resistance; finished parts are brass, bronze or stainless steel; stainless steel springs; nylon bearings.

Projection: 3-1/4" (83mm) active, 2-3/4" (70mm) dogged.

Dogging: Standard: single point 1/4 turn hex key dogging.

Fasteners: Standard: machine screws.

Strike: Top: Adjustable roller strike with positive locking plate and shims. Bottom: flush mounted.

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 6, Grade 1. Meets A117.1 Accessibility Code. UL/cUL All devices listed for safety as panic hardware; devices comply with UL 305. UL symbol on active case cover indicates listing. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. ADA Exit devices, lever trims and pulls comply with Americans with Disabilities Act.
