Alarmed Exit Devices

Barzel Lock Stocks All Alarmed Exit Devices In All Options & Finishes.
Qty Price
Buy 1 $ 190.00 ea
Buy 2 $ 180.50 ea
Buy 4 $ 174.80 ea

Detex ECL-230D Battery Alarmed Deadbolt Panic Device ECL-230D-PH. The ECL-230 is a code compliant, battery alarmed, rugged dead bolt, panic device with steel plate and photo-luminescent sign providing managed security and a 100 decibel alarm for secondary exits.

Instructions Video For Detex ECL-230D/ECL-230D-PH

• Attack resistant design withstands over 2200 lbs. of outside pull force

• Proven durability and reliability at a reasonable price

• Reduces employee and customer theft

• Single point, 1" throw dead bolt

• Saw resistant dead bolt

• Corrosion resistant alloy lock body

• 100 decibel alarm, powered by 9-volt battery (included)

• Easy to install

• Door Types - Wood, Hollow Metal or Aluminum

• Door Thickness - Fits standard 1-3/4" - 2-1/4"

• Minimum standard door width for ECL-230D is 20"

• Minimum standard door width for ECL-230D-PH is 34"

• Time tested construction resists attack from the inside

• Durable steel plate with photo luminescent sign absorbs light to then “glow in the dark” when lights are dimmed

• Easy to see if the lights go out

• Straightforward operation that everyone understands

• Accepts 5-pin through 7-pin standard and interchangeable core rim cylinders

• Resetting the alarm can only be accomplished with a control key

• Non-handed

• Locking and unlocking the dead bolt always arms and disarms the alarm

Detex ECL-230X Deadbolt Panic Device Alarm Grey

The ECL-230X is a code compliant, battery alarmed, rugged dead bolt, panic device with photoluminescent sign providing maximum security and a 100 decibel alarm for secondary exits.

Attack resistant design for maximum holding force

• Proven durability and reliability at a reasonable price

• Easy to install

• Dead bolt lock -1” throw with just over 3/4” engagement with the frame

• Saw resistant dead bolt

• Corrosion resistant alloy lock body

• 100 decibel alarm, powered by 9-volt battery (included)

• Surface/flush reversible strike

• Reduces employee and customer theft

• Time tested construction resists attack from the inside

• One size fits 36”-48” doors for code compliant acceptance

• For additional security with 4 locking points, specify ECL-230X-DX3

• Easy to see if the lights go out

• Straightforward operation that everyone understands

• Accepts 5-pin through 7-pin standard and interchangeable core rim cylinders without using cylinder collar

• Durable photo-luminescent sign absorbs light to then "glow in the dark" when lights are dimmed

• Locking and unlocking (dead bolt) always arms and disarms the alarm

• Non-handed

• Low profile meets International Building Code requirement allowing for 4” maximum projection off face of door

• Resetting the alarm can only be accomplished with a control key

• For 9VDC hardwiring add BE-961-1 or BE-961-2

Barzel Hardware Stocks The Full Detex Line. The ECL-230X-TDB is a code compliant, battery alarmed, rugged 3-point dead bolt, panic device with photo-luminescent sign providing maximum security and a 100 decibel alarm for secondary exits. Independent laboratory testing shows that the ECL- 230X-TDB can withstand up to 16,000 pounds of pull force.

Detex ECL-230X-TDB Intructions Video

• Reduces employee and customer theft

• Attack resistant design for maximum holding force

• Proven durability and reliability at a reasonable price

• Easy to install

• 3-point, 1" throw dead bolt lock with just over 3/4” engagement with the frame, and 3/4” throw top and bottom locks with 5/8” engagement with the strike

• Saw resistant dead bolts

• Corrosion resistant alloy lock body

• 100 decibel alarm, powered by 9-volt battery (included)

• Time tested construction resists attack from the inside

• One size fits 36”-48” doors for code compliant acceptance

• For maximum security with 6 locking points, specify ECL-230X-TDB-DX3

• Easy to see if the lights go out

• Straightforward operation that everyone understands

• Surface/flush reversible strike

• Accepts 5-pin through 7-pin standard and interchangeable core rim cylinders without using cylinder collar

• Durable photo-luminescent sign absorbs light to then "glow in the dark" when lights are dimmed

• Locking and unlocking the dead bolt always arms and disarms the alarm

• Non-handed

• Low profile meets International Building Code requirement allowing for 4” maximum projection off face of door

• Resetting the alarm can only be accomplished with a control key

• For 9VDC hardwiring add BE-961-1 or BE-961-2

Detex ECL-600 Exit Device Fire Rated Alarm

Fire-Rated Exit Control Hardware Features Benefits The ECL-600 is a fire rated, code-compliant, rugged, dependable relatching exit device with a steel plate and photo-luminescent sign providing managed security and a 100 decibel alarm for secondary fire exits.

Instructions For Detex ECL-600

• Gray Finish (Std.)

• Black Finish (BK) Mechanical Options

• English Push Plate Sign (Std.)

• Other Languages available (call factory for details)

• For Panic Hardware see ECL-230D or ECL-230D-PH ECL-620 ECL-600 Also available in Black (Cylinders and bar guard sold separately)

• Attack resistant design withstands over 2200 lbs. of outside pull force

• Proven durability, reliability and long service life at a reasonable price

• Reduces employee and customer theft

• Easy to Install

• Time tested construction resists attack from the inside

• Easy to see if the lights go out

• Straightforward operation that everyone understands

• 1" throw dead bolt and 3/4" dead locking latch bolt

• Relatching for additional security

• Saw resistant dead bolt

• Corrosion resistant alloy lock- body

• 100 decibel alarm, powered by 9-volt battery (included)

• Accepts 5-pin through 7-pin standard and interchangeable core rim cylinders

• Durable steel plate with photo luminescent sign

• Non-handed

• Locking and unlocking the dead bolt always arms and disarms the alarm

• Resetting the alarm can only be accomplished with a control key

Detex V40 EB Cylinder Dogging Alarmed Rim Exit Device

Detex V40 EB Cylinder Dogging Alarmed Rim Exit Device

The V40 EB is designed for primary and secondary exits that require an alarmed panic device. The 100dB alarm will sound when someone attempts to exit, alerting management to the unauthorized exit. Barzel Lock Stocks The V40 EB CD In All Options.

Instructions For Detex V40 EB CD

Benefits:

Priced to be the best value for durable and attractive loss prevention panic hardware

• Reduces employee and customer theft
• Fast and easy installation
• Secure installation prevents mistakes, enhances security and reduces maintenance
• Durable design provides years of trouble-free protection, saving on replacement costs
• Fits almost any door in any décor
• Controls foot traffic, deters unauthorized exits, prevents loss and meets building code requirements
Features:
• V40xEB - Alarmed Exit Device powered by standard 9-volt battery
• Stainless steel, 3/4" deadlocking Pullman-type latch bolt
• 100 decibel alarm
• 1/8 turn cylinder dogging
 • Heavy-duty angled end cap
• Heavy-duty ribbed aluminum rail extrusion
• Accommodates all types of mortise cylinders with a standard Yale cam (collar required for 7-pin IC cylinders)
• Patented back plate and plastic strike locator provide paperless template for perfect alignment with door and frame
• Single mortise cylinder (sold separate) provides arming and dogging
• State-of-art electronics offer reliable security and instantaneous alarm
• Field selectable key rearm or 2 min. auto rearm
• Visual and audible arming indicators • Armed and disarmed field selectable status indicator
Mechanical Options:
• CD - Cylinder Dogging (Std.)
 • 36 - Fits 36" Door Width (Std.)
• 48 - Fits 48" Door Width
• 99 - Surface Strike (Std.)
• 98 - Semi Mortise Strike

The V40xEBxW device option is designed for doors and gates requiring a stand alone, battery powered, alarmed, weatherized panic device. The alarm, with approximately 100dB, will sound when someone attempts to exit, alerting management that an unauthorized exit has occurred. The internal alarm with both remote bypass and remote signaling capabilities is ideal for applications where both security and life safety are a concern. In addition to listing as UL panic and fire exit hardware device, this device conforms to MIL-STD 810F Method 506.4 (driving rain test), MIL-STD 810F, Method 509.4 (salt fog test) and UBC standard 7-2 (positive pressure).

Barzel Lock Stocks The Detex V40 EB W CD In All Options

Video Instructions For Detex V40 EB W CD

Benefits:

• Weather resistant loss prevention hardware designed for use in outdoor or wet environments

• Patented back plate and plastic strike locator designed for perfect alignment with door and frame without paper template

• Fast, easy, trouble-free installation prevents costly mistakes and enhances security

• Provides reliable loss prevention protection 24 hours a day

• Controls foot traffic to deter unauthorized exits and reduces employee and customer theft • Rugged, durable, corrosionresistant design reduces maintenance

• Aesthetically pleasing design for almost any door or gate in any décor

Features:

• Powered by standard 9-volt battery

• Stainless steel, self-latching bolt

• Angled end cap deflects damage

• Tamper-resistant, immersion- proof security switches

• Covers a 161 door prep

• Plated steel, anodized aluminum and ABS components endure heavy use and exposure to the elements

 • Built-in inhibitors prevent ABS fading and weakening, typically caused by exposure to extreme temperatures and UV rays

• 100dB alarm

• Indefinite alarm requiring manual rearm or variable 2 min. alarm duration with auto re-arm

• Cylinder dogging standard (can also be ordered less dogging)

 • Visual and audible arming indicators

• Tamper-resistant housing protects electronics, battery and internal hardware, preventing manipulation

• Tapered design sheds rainwater

• Visual and audible low battery alert

• Armed and disarmed field selectable status indicator

Mechanical Options:

• CD - Cylinder Dogging (Std.)

• 36 - Fits 36" Door Width (Std.)

• 48 - Fits 48" Door Width

• 99 - Surface Strike (Std.)

• 98 - Semi Mortise Strike
